15KW induction gold melting machine (UM-15C-MF)
Views Send Enquiry
- Type: UM-15C-MF
- Parameter: Download PDF Catalog
- Attn:The photos in this page are reference only, and the actual delivered goods shall prevail!
Parameters of Induction Gold Melting Machines:
Type | Output Power | Input Current | Absorbed Power | Max. Frequency | Input Voltage | Melting Capacity | Melting Materials |
---|---|---|---|---|---|---|---|
UM-05C-MF | 6KVA | 23A | 5KW | 20KHz | 220VAC, 50Hz, Single Phase | 1~3KG/3~6 minutes | Gold, silver, platinum, copper |
UM-05C-RF | 6KVA | 27A | 6KW | 60KHz | 220VAC, 50Hz, Single Phase | 1~3KG/3~6 minutes | Gold, silver, platinum, copper |
UM-05C-HF | 6KVA | 27A | 6KW | 100KHz | 220VAC, 50Hz, Single Phase | 1~3KG/3~6 minutes | Gold, silver, platinum, copper |
UM-15C-MF | 15KVA | 15A | 10KW | 20KHz | 220VAC, 50Hz, Single Phase | 1~4KG/2~5 minutes | Gold, silver, platinum, copper |
UM-15C-HF | 15KVA | 15A | 10KW | 100KHz | 220VAC, 50Hz, Single Phase | 1~4KG/2~5 minutes | Gold, silver, platinum, copper |
UM-25C-MF | 25KVA | 30A | 20KW | 20KHz | 380VAC, 50Hz, Three Phase | 4~8KG/2~5 minutes | Gold, silver, platinum, copper |
UM-25C-RF | 25KVA | 30A | 20KW | 50KHz | 380VAC, 50Hz, Three Phase | 4~8KG/2~5 minutes | Gold, silver, platinum, copper |
15KW induction gold melting machine
